組立式ボールバルブ
020300
- Product Features
- ● Working Pressure: 0-150 psi
- ● Working Temperature: 0-60 ℃
- ● Pressure Test: Body (25Bar)， Seat(20Bar)
- ● Thread End: NPT ， BSPT
- ● Socket End: CNS， ANSI， BS， JIS， DIN
- ● Distinctive design of the seat where it is between on the ball and body。It guarantee that tightness is good while turn on or off ball valve。
- ● The element of PVC ball valve is not to add lead，no heavy metal、no poison、no smell。
- ● Handle、axis and ball use plastic (ABS) which is durable and not to get rusty。
- ● Axis use double o-ring which get better airtight。
- ● Every Assembled Ball Valve pass multiple pressure test which guarantee not to leak。
- Available For:
- ● The Assembled Ball Valve is used in a wide range of applications，including flow control and shutoff。 ● It is suitable for water supply to house、waste water treatment、agriculture、agricultural irrigation、multiple industrial use， etc。
- Weight
- 1/2”(84g)， 3/4”(135g)， 1”(200g)， 2-1/2”(1973g)， 3”(2804g)， 3-1/2”(2714g)， 4”( 4617g)， 5”(5019g)， 6”(5515g)
- Color:
- Gray
